Kadee O Scale 806 Short Plastic Couplers with Plastic Short Gearboxes – Black
This industry leading coupler features Original Style Head Short Centerset Plastic Couplers, and 850 O Scale centering spring and comes complete with Short Plastic Gearboxes and lids. The 743 Metal Coupler may be mounted with the included Short Plastic Gearbox (806 type).
It is not recommended to use a metal coupler directly on a metal surface or in a metal draft gearbox to avoid possible electrical crossover and shorting that may cause damage.
One pair per package
UPC: 765484008064
USA FlagMade in the U.S.A.
O-Scale
Simple Drop in Design
Trouble Free Operation
Compatible with All Kadee® O-Scale Couplers
World-Renowned Quality & Performance
They just Last & Last & Last…
Package Includes:
(2) Each 806 Original Style Plastic Couplers – Short Centerset Shank
(2) Each Short Plastic Gearboxes & lids (806 type)
(3) Each 850 O Scale Centering Springs
806 Plastic Coupler Features:
Material -Plastic
Shank Length -Short (47/64″) (Knuckle pulling face to center hole of Draft Gearbox)
Coupler Offset -Centerset
Centering Spring -850 O Scale Centering Springs
Knuckle Spring -845 O Scale Knuckle Springs
Head -Original Style Head
Works In Place of -743 O Scale Short Centerset Shank Couplers
Works With -806 type Draft Gearboxes
Plastic Short Draft Gearboxes & Lids Features (806 type):
Material -Plastic
Dimensions -17/32″L x 1/2″W x 7/32″H
Works With -743, & 806 Couplers
Mounting Specifications:
Mounting Height -25/32″
Centerline -1 1/16″
Trip Pin Height -1/16″
Mounting Holes -2-56 Insulated Screws are the most commonly used. (Screw length will vary)
